Fiberlogy BVOH: Water-Soluble Filament
Fiberlogy BVOH is a copolymer of butanediol and vinyl alcohol, designed for creating temporary supports in 3D printing. This filament allows for the printing of complex objects where traditional supports would be difficult to remove or would not yield satisfactory results. With BVOH filament, printing complex 3D objects is extremely easy.
Supports created with BVOH filament are very easy to remove. After printing, simply immerse the model in warm water, where the supports will completely dissolve. This results in a much higher quality model compared to supports that need to be broken off.
BVOH filament is compatible with dual extruder printers and has high adhesion to various types of materials, such as PLA, ABS, PET-G, ASA, flexible filaments (e.g., TPU), and others.
Main Advantages of Fiberlogy BVOH Filament
- Soluble in warm water
- High adhesion to PLA, ABS, ASA, PET-G, TPU, and other filaments
- Environmentally friendly – can be disposed of in household drainage
It is important to store the filament in a dry place, such as in a sealed bag, to prevent moisture absorption and subsequent deterioration of its properties.
Recommended Uses and Applications
- Prototypes: functional prototypes, hollow models, small models
- Decorations: complex structures, detailed ornaments, vases, jewelry
- Mechanisms: movable parts, mechanisms printed as a whole
Technical Specifications
- Diameter: 1.75 mm
- Net Weight: 0.5 kg
How to Print with BVOH Filament?
Recommended printing parameters for this material. To ensure the best print quality, appropriate settings for the specific printer and printing conditions must be chosen.
- Nozzle Temperature: 190-220°C
- Bed Temperature: 50-70°C
- Closed Chamber: not required
- Fan: 75-100%
- Flow Rate: 95-105%
- Print Speed: < 35 mm/s
- Retraction (direct drive): 2-3 mm
- Retraction (Bowden): 4-6 mm
- Retraction Speed: 20-45 mm/s
- Drying Conditions: 50°C / 4h
Note: Protect from moisture (store filament in well-sealed packaging when not in use).
Color | ![]() |
---|---|
Manufacturer | Fiberlogy |
Filament weight | 0.5 kg |
Filament material | BVOH |
Compatible with AMS | Yes |
Compatible with AMS Lite | Yes |
Filament diameter | 1,75 mm |
Heated bed temperature | 50 - 70 °C |
Hotend temperature | 190-220°C |
Diameter tolerance | ± 0,02 mm |
Spool diameter | 200 mm |
Spool width | 86 mm |
Spool hole diameter | 52 mm |
Closed chamber | Not required |
Roundness tolerance | ± 0,01 mm |
Difficulty of printing | Advanced |
Drying conditions | 50 °C / 4h |
Heat Distortion Temp | 70 °C |
